AAS-LS Monumental Panoramic Living

Lift & Slide Windows

Heavy-capacity architectural sliding systems where rotating the handle lifts the sash off the seals to effortlessly glide monumental glass panels up to 400kg.

← Back to All Catalogues

Frame Depth

100mm - 160mm

Glass Range

12mm to 48mm DGU / TGU

Max Sash Weight

400 kg per sash

Thermal Barrier

Heavy Thermal Break

Air Tightness

Class 4 (EN 12207)

Water Tightness

Class 9A (EN 12208)

Wind Resistance

Class C5 (EN 12210)

System Overview

Engineering & Performance Highlights

For monumental architectural openings where ordinary sliding doors reach their limit, the AAS Lift & Slide system delivers extraordinary performance. When the heavy-duty handle is rotated downward, an internal mechanical gear lever lifts the entire glass sash 8mm upward off the bottom weather seals onto heavy-duty stainless steel tandem bogies, allowing sashes weighing up to 400 kg to glide with fingertip ease. When rotated closed, the sash lowers back down, compressing heavy EPDM gaskets against the track for unmatched air, water, and acoustic sealing.

Key Engineering Advantages

Massive sash capacity carrying up to 400 kg per panel with effortless glide
Zero-threshold flush floor integration creating seamless transitions between indoors and patio
90-degree pillarless open corner designs for breathtaking uninterrupted panoramic vistas
Advanced thermal barrier technology accommodating triple glazing up to 48mm
Soft-close braking dampener preventing slamming and ensuring safe family operation
